Mazda MVP Premacy BT50 8C Key Programming
Step 1:
Unprogrammed Key into Ignition for more than 1sec
Step 2:
Key out then in 1cm 5x at no more than 1sec intervals
Step 3:
After final insertion immo light will flash (@300ms)
Step 4:
Wait 5min until immo light slows to 1.2sec
Step 5: Enter PIN.
To enter Pin, turn key to ON position when immo light is off and then let light flash the amount of times as the first number of pin
Turn key to LOCK position
Wait at least one flash before turning key back to ON and repeating the same process for the remaining digits of the pin
Step 6:
Turn ignition on when immo light is off
Step 7:
Wait for the number of illuminations of the 1st digit of the PIN
Step 8:
When immo light is off turn ign off
Step 9:
Wait at least 1 illumination cycle but less than 30sec
Step 10:
Repeat steps 7-9 for the remaining 7 digits of the PIN
Step 11:
When correctly entered immo light will illuminate
Step 12: Turn key on
Step 13:
Immo light will illuminate for 1-2sec
Step 14:
After immo light goes out remove the key
Step 15:
Repeat 12-14 for subsequent keys
Step 16: Wait 30sec
Step 17: Check all Keys work
Notes:
Minimum 2 Maximum 8 Keys
Manufacturer | . |
---|---|
Button Config | NA |
Market | Any |
